Specifications
Availability45 pcs
BrandINA
Item NumberBK2016-A INA
Manufacturer Part Number0001770590000
EAN4012802432503
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
20
Outer (D) MM
26
Width (B) MM
16
Inner (d) Inch
0.7874
Outer (D) Inch
1.0236
Width (B) Inch
0.6299
Weight (kg)
0.024
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
20
Radial Static Load Rating C0r (N)
20100
Radial Dynamic Load Rating Cr (N)
12700
Limiting speed (n G)
12700
Limiting speed for grease lubrication (n G Grease)
7600
Reference speed (n ϑr)
9300
ECLASS number
23-05-09-06
ECLASS2 number
23-05-09-06
Medias description
Drawn cup needle roller bearings with closed end BK, to DIN 618/ISO 3245
Suffix description
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
