Specifications
Availability10 pcs
BrandINA
Item NumberBK2020-AS1-A INA
Manufacturer Part Number0002292530000
EAN4012802425048
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Weight (kg)
0.027
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
20
Basic static load rating, radial (C 0r)
26000
Limiting speed (n G)
12700
Limiting speed for grease lubrication (n G Grease)
7600
Reference speed (n ϑr)
9300
ECLASS number
23-05-09-06
ECLASS2 number
23-05-09-06
Suffix description
AS1Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
