Specifications
Availability378 pcs
BrandINA
Item NumberHF0612-L564 INA
Manufacturer Part Number (MPN)0013721730962
Also known as
HF0612
EAN4047643184625
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
6
Outer (D) MM
10
Width (B) MM
12
Inner (d) Inch
0.2362
Outer (D) Inch
0.3937
Width (B) Inch
0.4724
Weight (kg)
0.003
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
6
Permissible torque (M d per)
1.76
Limiting speed for rotating shaft (n GW)
23000
Limiting speed for rotating outer ring (n GA)
13000
ECLASS number
23-05-21-90
ECLASS2 number
23-05-21-90
Medias description
Drawn cup roller clutches HF, with steel springs
Suffix description
L564Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
