Specifications
Availability320 pcs
BrandINA
Item NumberHFL1626-L564 INA
Manufacturer Part Number (MPN)0016002060962
Also known as
HFL1626
EAN4012802369274
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
16
Outer (D) MM
22
Width (B) MM
26
Inner (d) Inch
0.6299
Outer (D) Inch
0.8661
Width (B) Inch
1.0236
Weight (kg)
0.022
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
16
Radial Static Load Rating C0r (N)
9000
Radial Dynamic Load Rating Cr (N)
7400
Limiting speed for rotating shaft (n GW)
8500
Limiting speed for rotating outer ring (n GA)
7500
ECLASS number
23-05-21-90
ECLASS2 number
23-05-21-90
Medias description
Drawn cup roller clutch HFL, with bearing
Suffix description
L564Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
