Loading equivalents
Specifications
Availability267 pcs
BrandINA
Item NumberHFL3530-L564 INA
Manufacturer Part Number0016002570962
Also known as
HFL3530
EAN4012802042702
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
35
Outer (D) MM
42
Width (B) MM
30
Inner (d) Inch
1.378
Outer (D) Inch
1.6535
Width (B) Inch
1.1811
Weight (kg)
0.058
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
35
Radial Static Load Rating C0r (N)
18800
Radial Dynamic Load Rating Cr (N)
12200
Limiting speed for rotating shaft (n GW)
3900
Limiting speed for rotating outer ring (n GA)
3900
ECLASS number
23-05-21-90
ECLASS2 number
23-05-21-90
Medias description
Drawn cup roller clutch HFL, with bearing
Suffix description
L564Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
