Loading equivalents
Specifications
Availability122 pcs
BrandINA
Item NumberHFLZ061014-A-L564 INA
Manufacturer Part Number0006062350962
Also known as
HFLZ061014
EAN4012802605808
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
9,53
Outer (D) MM
15,88
Width (B) MM
22,23
Inner (d) Inch
0.375
Outer (D) Inch
0.625
Width (B) Inch
0.875
Weight (kg)
0.014
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
9,525
Basic static load rating, radial (C 0r)
5500
Limiting speed for rotating shaft (n GW)
14000
Limiting speed for rotating outer ring (n GA)
12000
ECLASS number
23-05-21-90
ECLASS2 number
23-05-21-90
Suffix description
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
L564Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
