Loading equivalents
Specifications
Availability114 pcs
BrandINA
Item NumberHK1516-B INA
Manufacturer Part Number0000592420000
EAN4012802432237
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
15
Outer (D) MM
21
Width (B) MM
16
Inner (d) Inch
0.5906
Outer (D) Inch
0.8268
Width (B) Inch
0.6299
Weight (kg)
0.0146
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
15
Width (C) mm
16
Radial Static Load Rating C0r (N)
14400
Radial Dynamic Load Rating Cr (N)
10500
Limiting speed (n G)
16500
Limiting speed for grease lubrication (n G Grease)
9900
Reference speed (n ϑr)
12300
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Medias description
Drawn cup needle roller bearings with open ends HK, to DIN 618/ISO 3245
Suffix description
BThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
