Specifications
Availability80 pcs
BrandINA
Item NumberHK2212-AS1-B INA
Manufacturer Part Number0000607040000
EAN4012802606461
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
22
Outer (D) MM
28
Width (B) MM
12
Inner (d) Inch
0.8661
Outer (D) Inch
1.1024
Width (B) Inch
0.4724
Weight (kg)
0.014
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
22
Width (C) mm
12
Basic static load rating, radial (C 0r)
13400
Limiting speed (n G)
11700
Limiting speed for grease lubrication (n G Grease)
7000
Reference speed (n ϑr)
8900
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Suffix description
AS1Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes
BThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
