Loading equivalents
Specifications
Availability32 pcs
BrandINA
Item NumberHK4518-RS-A-L271 INA
Manufacturer Part Number0002563310968
EAN4012802585506
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
45
Outer (D) MM
52
Width (B) MM
18
Inner (d) Inch
1.7717
Outer (D) Inch
2.0472
Width (B) Inch
0.7087
Weight (kg)
0.064
Product Properties
Seal
RS - Rubber Seal on One Side
Data from Schaeffler (medias)
Under roller diameter (F w) mm
45
Width (C) mm
18
Radial Static Load Rating C0r (N)
43000
Radial Dynamic Load Rating Cr (N)
21300
Limiting speed (n G)
3550
Limiting speed for grease lubrication (n G Grease)
3550
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Medias description
Drawn cup needle roller bearings with open ends HK..-RS, lip seal on one side, to DIN 618
Suffix description
RSOne Seal, Buna-N Rubber, Radial Type
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
