Loading equivalents
Specifications
Availability89 pcs
BrandINA
Item NumberHK5024-2RS-A-L271 INA
Manufacturer Part Number (MPN)0002452400968
Also known as
HK5024-2RS
HK5024-2RS-A
EAN4012802369144
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Outer (D) MM
58
Width (B) MM
24
Outer (D) Inch
2.2835
Width (B) Inch
0.9449
Weight (kg)
0.086
Product Properties
Seal
2RS - Rubber Seal on Two Sides
Data from Schaeffler (medias)
Under roller diameter (F w) mm
50
Radial Static Load Rating C0r (N)
63000
Limiting speed (n G)
3150
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Medias description
Drawn cup needle roller bearings with open ends HK..-2RS, lip seals on both sides, to DIN 618
Suffix description
2RSLip Seals On Both Sides
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
