Specifications
Availability6 pcs
BrandINA
Item NumberHK5024-2RS-AS1-A-L271 INA
Manufacturer Part Number0013828880968
EAN4054364527877
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
58
Width (B) MM
24
Weight (kg)
0.086
Product Properties
Seal
2RS - Rubber Seal on Two Sides
Data from Schaeffler (medias)
Under roller diameter (F w) mm
50
Basic static load rating, radial (C 0r)
63000
Limiting speed (n G)
3150
Limiting speed for grease lubrication (n G Grease)
3150
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Suffix description
2RSLip Seals On Both Sides
AS1Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
