Specifications
Availability150 pcs
BrandINA
Item NumberK21X25X17-D-A/0-7 INA
Manufacturer Part Number0001822656063
EAN4012802718072
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
21
Outer (D) MM
25
Width (B) MM
17
Inner (d) Inch
0.8268
Outer (D) Inch
0.9843
Width (B) Inch
0.6693
Weight (kg)
0.014
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Outside diameter of needle roller complement (E w) mm
25
Width (B c) mm
17
Basic static load rating, radial (C 0r)
19400
Limiting speed (n G)
20900
Reference speed (n ϑr)
12300
ECLASS number
23-05-09-04
ECLASS2 number
23-05-09-04
Suffix description
DThe Half Of A Whole Needle Roller
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
