Loading equivalents
Specifications
Availability99 pcs
BrandINA
Item NumberK28X33X13-B/-1-3 INA
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
28
Outer (D) MM
33
Width (B) MM
13
Inner (d) Inch
1.1024
Outer (D) Inch
1.2992
Width (B) Inch
0.5118
Weight (kg)
0.015
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Outside diameter of needle roller complement (E w) mm
33
Width (B c) mm
13
Basic static load rating, radial (C 0r)
24200
Limiting speed (n G)
16100
Reference speed (n ϑr)
8900
ECLASS number
23-05-09-04
ECLASS2 number
23-05-09-04
Suffix description
BThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
