Loading equivalents
Specifications
Availability4 pcs
BrandINA
Item NumberNA4832-XL-2S INA
Manufacturer Part Number0507685140954
Also known as
NA4832-2S
EAN4054363037506
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
160
Outer (D) MM
200
Width (B) MM
40
Inner (d) Inch
6.2992
Outer (D) Inch
7.874
Width (B) Inch
1.5748
Weight (kg)
2.89
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Width (b) mm
40
Basic static load rating, radial (C 0r)
435000
Limiting speed (n G)
2700
Reference speed (n ϑr)
1650
ECLASS number
23-05-09-07
ECLASS2 number
23-05-09-07
Suffix description
XLX-Life
2SIf Two Or More Bearings Are Located Adjacent To Each Other In A Planet (2, 3 Or 4 Bearings), These Must Be Ordered Using The Suffix 2S, 3S Or 4S So That They Are Sorted Together
