Home › Needle Roller and Cage Assembly › NKIS25-XL INA

NKIS25-XL INA

Needle roller bearings NKIS, heavy series

50 pcs expected on Thu 10 Jul

This product is available from stock
Orders placed before 6 p.m. CEST will be shipped today
Payment by invoice possible
Track your order with track & trace
Official Schaeffler distributor

Loading equivalents

Specifications

Availability 50 pcs expected on Thu 10 Jul
Brand INA
Item Number NKIS25-XL INA
Manufacturer Part Number 0507709850000
Also known as NKIS25
EAN 4054363051601
Category Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM 25
Outer (D) MM 47
Width (B) MM 22
Inner (d) Inch 0.9843
Outer (D) Inch 1.8504
Width (B) Inch 0.8661
Weight (kg) 0.174

Product Properties

Seal No Seal

Data from Schaeffler (medias)

Width (b) mm 22
Radial Static Load Rating C0r (N) 43500
Radial Dynamic Load Rating Cr (N) 38000
Basic static load rating, radial (C 0r) "43500.0000"
Limiting speed (n G) 13200
Limiting speed for grease lubrication (n G Grease) 7900
Reference speed (n ϑr) 7100
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKIS, heavy series

Suffix description

XL X-Life

Downloads & Links
