Specifications
Availability79 pcs
BrandINA
Item NumberNKS75-A INA
Manufacturer Part Number0007737270000
EAN4012802417074
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
75
Outer (D) MM
95
Width (B) MM
28
Inner (d) Inch
2.9528
Outer (D) Inch
3.7402
Width (B) Inch
1.1024
Weight (kg)
0.402
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm
75
Radial Static Load Rating C0r (N)
123000
Radial Dynamic Load Rating Cr (N)
71000
Limiting speed (n G)
6000
Limiting speed for grease lubrication (n G Grease)
3600
Reference speed (n ϑr)
3950
ECLASS number
23-05-09-07
ECLASS2 number
23-05-09-07
Medias description
Radial roller bearing NKS..-A
Suffix description
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
