Loading equivalents
Specifications
Availability20 pcs
BrandINA
Item NumberNKXR50-XL INA
Manufacturer Part Number0507808670000
Also known as
NKXR50
EAN4012802736076
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
62
Width (B) MM
35
Inner (d) Inch
1.9685
Outer (D) Inch
2.4409
Width (B) Inch
1.378
Weight (kg)
0.27
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (C) mm
35
Radial Static Load Rating C0r (N)
74000
Radial Dynamic Load Rating Cr (N)
43000
Axial Static Load Rating C0a (N)
177000
Axial Dynamic Load Rating Ca (N)
62000
Limiting speed (n G)
4800
Reference speed (n ϑr)
1700
ECLASS number
23-05-12-03
ECLASS2 number
23-05-12-03
Medias description
Needle roller/axial cylindrical roller bearings NKXR, axial component, single direction, to DIN 5429, without end cap, for oil lubrication
