Specifications
Availability31 pcs
BrandINA
Item NumberNKXR50-Z-XL INA
Manufacturer Part Number0507922450000
Also known as
NKXR50-Z
EAN4012802736281
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
62
Width (B) MM
35
Inner (d) Inch
1.9685
Outer (D) Inch
2.4409
Width (B) Inch
1.378
Weight (kg)
0.286
Product Properties
Seal
Z - Steel Seal on One Side
Data from Schaeffler (medias)
Height (C) mm
35
Radial Static Load Rating C0r (N)
74000
Radial Dynamic Load Rating Cr (N)
43000
Axial Static Load Rating C0a (N)
177000
Axial Dynamic Load Rating Ca (N)
62000
Limiting speed (n G)
4800
Reference speed (n ϑr)
1700
ECLASS number
23-05-12-03
ECLASS2 number
23-05-12-03
Medias description
Needle roller/axial cylindrical roller bearings NKXR..-Z, axial component, single direction, to DIN 5429, with end cap, for grease lubrication
Suffix description
ZShield Of Pressed Sheet Steel On One Side Of The Bearing
