Specifications
Availability3 pcs
BrandINA
Item NumberZARF50140-L-TV-A INA
Manufacturer Part Number0016831870000
EAN4012802420159
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
140
Width (B) MM
103
Inner (d) Inch
1.9685
Outer (D) Inch
5.5118
Width (B) Inch
4.0551
Weight (kg)
4.65
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (H) mm
103
Radial Static Load Rating C0r (N)
103000
Radial Dynamic Load Rating Cr (N)
46500
Axial Static Load Rating C0a (N)
480000
Axial Dynamic Load Rating Ca (N)
172000
Limiting speed for grease lubrication (n G Grease)
1100
Limiting speed for oil lubrication (n G Oil)
3100
ECLASS number
23-05-12-03
ECLASS2 number
23-05-12-03
Medias description
Needle roller/axial cylindrical roller bearings ZARF..-L, double direction, for screw mounting, long shaft locating washer
Suffix description
LLong Locating Washers
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
