Specifications
Availability10 pcs
BrandINA
Item NumberZARN1545-TV-A INA
Manufacturer Part Number (MPN)0016818930000
EAN4012802439892
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
15
Outer (D) MM
45
Width (B) MM
40
Inner (d) Inch
0.5906
Outer (D) Inch
1.7717
Width (B) Inch
1.5748
Weight (kg)
0.34
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (H) mm
40
Radial Static Load Rating C0r (N)
17500
Radial Dynamic Load Rating Cr (N)
13000
Axial Static Load Rating C0a (N)
53000
Axial Dynamic Load Rating Ca (N)
24900
Limiting speed for grease lubrication (n G Grease)
2200
Limiting speed for oil lubrication (n G Oil)
8500
ECLASS number
23-05-12-90
ECLASS2 number
23-05-12-90
Medias description
Needle roller/axial cylindrical roller bearings ZARN, double direction
Suffix description
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
