Specifications
Availability9 pcs
BrandINA
Item NumberZARN3585-TV-A INA
Manufacturer Part Number0016828140000
EAN4012802439984
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
35
Outer (D) MM
85
Width (B) MM
66
Inner (d) Inch
1.378
Outer (D) Inch
3.3465
Width (B) Inch
2.5984
Weight (kg)
1.65
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (H) mm
66
Radial Static Load Rating C0r (N)
53000
Radial Dynamic Load Rating Cr (N)
27500
Axial Static Load Rating C0a (N)
265000
Axial Dynamic Load Rating Ca (N)
105000
Limiting speed for grease lubrication (n G Grease)
1250
Limiting speed for oil lubrication (n G Oil)
4000
ECLASS number
23-05-12-90
ECLASS2 number
23-05-12-90
Medias description
Needle roller/axial cylindrical roller bearings ZARN, double direction
Suffix description
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
