Loading equivalents
Specifications
Availability8 pcs
BrandINA
Item NumberZARN50110-TV-A INA
Manufacturer Part Number0016831440000
EAN4012802443226
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
110
Width (B) MM
82
Inner (d) Inch
1.9685
Outer (D) Inch
4.3307
Width (B) Inch
3.2283
Weight (kg)
3.38
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (H) mm
82
Radial Static Load Rating C0r (N)
103000
Radial Dynamic Load Rating Cr (N)
46500
Axial Static Load Rating C0a (N)
480000
Axial Dynamic Load Rating Ca (N)
172000
Limiting speed for grease lubrication (n G Grease)
1100
Limiting speed for oil lubrication (n G Oil)
3100
ECLASS number
23-05-12-90
ECLASS2 number
23-05-12-90
Medias description
Needle roller/axial cylindrical roller bearings ZARN, double direction
Suffix description
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
