Also known as
ARNB55115
AXZN55115TN
TARN55115
ZARN55115TN
EAN4012802443264
CategoryNeedle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM
55
Outer (D) MM
115
Width (B) MM
82
Inner (d) Inch
2.1654
Outer (D) Inch
4.5276
Width (B) Inch
3.2283
Weight (kg)
3.5
Product Properties
Seal
No Seal
Data from Schaeffler (medias)
Height (H) mm
82
Radial Static Load Rating C0r (N)
98000
Radial Dynamic Load Rating Cr (N)
44000
Axial Static Load Rating C0a (N)
500000
Axial Dynamic Load Rating Ca (N)
177000
Limiting speed for grease lubrication (n G Grease)
1000
Limiting speed for oil lubrication (n G Oil)
2900
ECLASS number
23-05-12-90
ECLASS2 number
23-05-12-90
Medias description
Needle roller/axial cylindrical roller bearings ZARN, double direction
Suffix description
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
